How to use Table mill to G-CODE

Creates a facing program that mills a rectangular table to a depth, moving along the X or the Y axis.

Open the app

Settings

Cutting type, coordinates, units and M codes work the same way in every cutting app. G-code settings explained

Setting	What you enter	Default
Tool Diameter required	Number	–
Table length required	Number	–
Table width required	Number	–
Depth required	Number	–
Movement required	One of: along the axis X · along the axis Y	`along the axis X`

Setting	What you enter	Default
Coordinates required	One of: Absolute · Incremental · Absolute - Incremental Arc centers	`Absolute`
Measurement unit required	One of: inch · mm · cm	`mm`
M codes on required	One of: Yes · No	`Yes`
